FlutLED-Ex 3 120W / 150W
Ex floodlight for zones 1, 2, 21 and 22
Robust aluminum housing with anti-corrosion coating |
Low energy consumption with high luminous efficacy |
Protection class up to IP66 for dusty and damp environments |
Shock and vibration resistant |
Suitable for floor, wall or ceiling mounting |
Optional on request with battery pack for emergency light 10W / 180 min. |
Description
The FlutLED-Ex 3 120W or 150W is suitable for all areas that require an efficient and extremely robust Ex luminaire. With its excellent light output, this Ex luminaire is used in areas such as refineries, the energy and chemical industries as well as on drilling platforms.
Product features
- High light output
- Shock and vibration resistant
- Robust aluminum housing with anti-corrosion coating
- tempered glass front panel
- optimum light distribution for different applications
- Through-wiring possible
- Cable gland Ex M20 x 1.5 and an M20 blanking plug included in the scope of delivery
Technical data
Marking: | Ex II 2 G – Ex db IIC T4/T5 Gb Ex II 2 D – Ex tb IIIC T105°/T95°C Db IP66 |
Ex-Zones: | 1, 2, 21, and 22 |
Inout voltage: | 100-277VAC (50/60Hz) |
Overvoltage protection: | 5kV |
System performance: | 60W |
Luminous flux: |
– 60° 13.920lm / 17.400lm
– 120° 16.380lm / 20.475lm
|
System efficiency: |
– 60° 116lm/W
– 120° 136lm/W
|
Light colour: | in middle 5.700K |
CRI-Index: | 70 |
Beam angle: | 80° or 120° |
LED service life: | >50.000h |
Protection category: | IP66 |
Housing colour: | RAL 7040 |
Temperature range of application: | -40° to +55°C |
Housing: | Die-cast aluminum |
Weight: | 11kg |
Dimensions (HxØ): | 330x197mm |
Assembly examples
Item no. | Description | Onlineshop |
316514 | FlutLED-Ex 3/W120/60° | on request |
316515 | FlutLED-Ex 3/W120/120° | on request |
316516 | FlutLED-Ex 3/W150/60° | on request |
316517 | FlutLED-Ex 3/W150/120° | on request |
Accessories
Item no. | Description | Onlineshop |
316518 | Swivel bracket, stainless steel* | on request |
316519 | Suspension ring, stainless steel | on request |
316520 | Protective grille | on request |
* Mandatory accessory 316518 Swivel bracket – Delivery condition: The luminaire is supplied without accessories as standard!
