Electrical equipment for potentially explosive gas atmospheres is subject to special requirements. This involves properties such as safety, encapsulation of the equipment and, last but not least, protection against sparks. Important protective functions can be achieved through various measures such as specially encapsulated housings. The high-quality cable reels in our range have outstanding product properties. For example, we offer cable reels made of conductive elastomer on a sturdy tubular steel frame with ball bearings. The cables with the minimum requirement of H07 are available in yellow or black, depending on customer requirements. They are rounded off with sturdy brass feet. They are characterized by a high mechanical load capacity and a design that is impact-resistant and resistant to ageing. They can be used in potentially explosive environments if the equipment is placed on conductive and earthed surfaces.

All product features at a glance:

• Cable reel in EX design
• Suitable for zones 1 and 2
• Reel body made of conductive elastomer
• GIFAS PROFLEXX H07 cable
• Sturdy tubular steel frame with ball bearings
• Crank handle can be turned and folded
• Locking via mechanical locking mechanism
• Stainless steel side plates for mounting the flange sockets as a connection to the frame
• Connection via Ex e terminals on the flange socket, with pivot bearing (instead of axle)
  “Use of the cable reel in a potentially explosive atmosphere of gas group IIC is only permitted if the cable is connected first or the cable reel is placed on a conductive floor or conductive and earthed surface.”
• Easy maintenance inside the reel (no additional encapsulation)
• Resistant to oils and greases, resistant to chemical influences
• UV and weather resistant
• High mechanical load capacity
• Impact-resistant and resistant to ageing
• Very good conductivity
  the minimum requirement for the cable is H07

Benefit from high-quality Ex products such as the 573 cable reel, which has an IP65 degree of protection and protection class II – it is suitable for zones 1 and 2. The impact-resistant and ageing-resistant cable reel is equipped with a rotating and folding ball handle and can withstand high mechanical loads. The product is also resistant to chemical influences and resistant to oils, acids, UV and a wide range of weather conditions. It is equipped with two CEE built-in sockets with 16A or one with 32A.

In addition to high-quality cable reels, distributors and connectors, we also supply other devices such as powerful LED lights in a wide variety of designs. These can be used in refineries and drilling platforms as well as in the energy and chemical industries. The high-quality spotlights are also used in disaster control. Other light sources consist of high-quality LED floodlights with outputs of up to 150 watts and a very long service life. Thanks to LED technology, these lights achieve a high level of efficiency.

Also available in safety-relevant technology are the Ex linear luminaires with their robust aluminum housings, which are also suitable for use in very demanding locations, for example in areas exposed to salt water or other liquids. You can also obtain smaller Ex machine or hand-held lights with efficient LED technology or powerful battery-powered lights for mobile use. If you have any further questions about Ex products, their areas of application and our range, please do not hesitate to contact us. Just get in touch with us!
