- In-built thermocouple can be installed on request for tangential fan control
- External screws are made from stainless steel and are captive
- Easy to service designs as all parts are individually replaceable
- Transformers according to VDE 0570, IEC 61558
- Safety isolated housings according to VDE 0100 part 410
Catalog-Download
Besondere Merkmale:
Technische Daten:
| Power: | 2,500–3,000 VA |
| Voltage: | 230 V / 230 V |
| Versions: | Block transformer |
Besondere Merkmale:
Miniature circuit breakers under transparent protective cap: 51 (17 per transparent protective cap)
Technische Daten:
| Dimensions: | 360 x 500 x 133 mm |
| Weight: | 13–20 kg |
| Protection category: | IP 54 |
Besondere Merkmale:
Miniature circuit breakers under transparent protective cap: 21 (17 + 4 per transparent protective cap)
Technische Daten:
| Dimensions: | 336 x 370 x 162 mm |
| Weight: | 9–13 kg |
| Protection category: | IP 54 |
Besondere Merkmale:
Miniature circuit breakers under transparent protective cap: 17 (13 + 4 per transparent protective cap)
Technische Daten:
| Dimensions: | 265 x 370 x 132 mm |
| Weight: | 8–12 kg |
| Protection category: | IP 54 |
Besondere Merkmale:
Miniature circuit breakers under transparent protective cap: 9
Technische Daten:
| Dimensions: | 200 x 350 x 132 mm |
| Weight: | 7–10 kg |
| Protection category: | IP 54 |
Besondere Merkmale:
Miniature circuit breakers under transparent protective cap: 7
Technische Daten:
| Dimensions: | 160 x 280 x 132 mm |
| Weight: | 5–8 kg |
| Protection category: | IP 54 |
Besondere Merkmale:
Miniature circuit breakers under transparent protective cap: 11
Technische Daten:
| Dimensions: | 250 x 360 x 132 mm |
| Weight: | 5–8 kg |
| Protection category: | IP 54 |
Besondere Merkmale:
- In-built thermocouple can be installed on request for tangential fan control
- External screws are made from stainless steel and are captive
- Easy to service designs as all parts are individually replaceable
- Transformers according to VDE 0570, IEC 61558
- Safety isolated housings according to VDE 0100 part 410
Technische Daten:
| Power: | 120–160 VA |
| Voltage: | 230 V / 230 V |
| Versions: | Toroidal core transformer |
Technische Daten:
| Dimensions: | 110 x 79 x 110 mm |
| Weight: | 1–2 kg |
| Protection category: | IP 54 |
Besondere Merkmale:
- Wired ready for connection
- Easy to service
- All parts are individually replaceable
Technische Daten:
| Dimensions: | H x B x T = 184 x 92 x 53 mm |
| Weight: | 1.5 kg |
Besondere Merkmale:
Machine units under transparent protective cover: 2
Technische Daten:
| Dimensions: | 160 x 90 x 160 mm |
| Weight: | 3 kg |
| Protection category: | IP 54 |
Besondere Merkmale:
- Wired ready for connection
- Available with a transparent protective cover for a maximum of two miniature circuit breakers
- Easy to service
- All parts are individually replaceable
Technische Daten:
| Dimensions: | H x B x T = 290 x 78 x 91 mm |
| Weight: | 2.0 kg |
Besondere Merkmale:
Machine units under transparent protective cover: 2
Technische Daten:
| Dimensions: | 125 x 125 x 76 mm |
| Weight: | 2 kg |
| Protection category: | IP 54 |
Besondere Merkmale:
- Different stainless steel housing sizes from 300x380 to 600x800 (in the standard V2A / 1.4301 / AISI 304 / Surface Finish)
- Internal electrical components installed in solid rubber distributor (different housing types) (solid rubber distributor mounted on removable mounting plate)
- Protection class II by combination with rubber housing
- Transparent protective cover as protection against contact with the security elements
- side vent (to reduce condensation)
- all-round foamed PU seal (empty housing IP66)
- Optionally available on request are also versions in sheet steel (surface dip-coated, powder-coated, RAL 7035) or in V4A stainless steel (AISI316L)
- Suitable for wall mounting (incl. Mounting brackets) or stand mounting (version with stand construction)
- Completely ready to connect, recorded routine test according to EN 61439
- Weight depending on the version of 22-60 kg
Technische Daten:
| Weight: | 22.00 - 60.00 kg |
| Protection category: | IP 54 |
